Asus RS500A-E12-RS4U-8TW Barebone System RS500A-E12-RS4U-8TW
Next1 In stock
Barebone Systems
Asus
To add this product to your wish list you must Sign In or Create an account
AMD EPYC™ 9004 single-processor 1U server that supports up to 24 DIMM, 4 NVMe, three PCIe® 5.0 slots, two M.2, OCP 3.0, two single-slot GPUs, and ASUS ASMB11-iKVM
KEY FEATURES
- Powerful performance:Powered by AMD EPYC 9004 processors with 96 Zen 4 cores, 12-channel, up to 4800 MHz DDR5 and support for a maximum TDP of up to 400 watts
- Scale-up storage and expansion design:Up to 4 all-flash NVMe drives on the front panel and 3 PCIe 5.0 slots for higher bandwidth and system upgrade
- Flexible networking module design:On-board LAN module, and OCP 3.0 module with PCIe 5.0 slot in rear panel for faster connectivity
- Advanced air cooling solution: Features enhanced volume air cooling (EVAC) heatsink for processors with higher TDP
- Enhanced IT-infrastructure management:ASUS ASMB11-iKVM remote control with ASPEED AST2600, ASUS Control Center IT management software and hardware-level Root-of-Trust solution
- Read for AI and HPC workloads:Up to two single-slot GPUs.
PCIe 5.0 Ready | Faster storage, graphics and networking capabilities
PCI Express® (PCIe®) 5.0 delivers 32GT/s bandwidth, which is twice the speed of PCIe 4.0, and offers lower power consumption, better land scalability and backwards compatibility. ASUS servers are PCIe 5.0 ready with scalability design to satisfy the increasing workloads for modern data center.
AMD EPYC™ 9004 Series Processors
The 9004 Series EPYC CPUs amplifies the AMD history of x86 architecture innovations and record-breaking performance with next generation 5nm technology as well as introducing support for high performant DDR5 DIMMs and fast PCIe® Gen 5 I/O. EPYC 9004 CPUs support 12 memory channels with 2 DIMMs/channel capability, delivering the resources needed for memory hungry AI, ML, HPC, and large in-memory computations.
World Records Leadership
ASUS holds the most amount of records in dual-socket (2P) and single-socket (1P) on SPEC CPU 2017 benchmark and dominate the computing performance. These top performance results provide a useful insight into compute-intensive workloads on different computer systems, enabling our customers to reduce complexity, tackle challenging workloads and accelerate system validations.
ASUS servers feature Performance Boost technology to achieve the best server performance and agility by tuning servers to match the requirements of workloads, letting you gain greater control of your server environment. This technology improves workload throughput by maximizing processor frequency and boost power, ideal for timesensitive applications such as financial services or data center operations.
Core Optimizer
Maximizes the processor frequency in multi-core operations, avoiding frequency shifting for reduced latency.
Remember, everything you buy at Lotsofstuff.ca is brand new shipped directly from our Canadian warehouses with full manufacturer's warranty. Huge selection, amazing prices and fast shipping. Order your Asus RS500A-E12-RS4U-8TW Barebone System today!
- Compatible EPYC processor lets you perform all your computational tasks at a swift pace
- DDR4 SDRAM compatible slot - Install memory that synchronizes electrical and clock signals for an efficient data throughput
- Up to 10x faster than standard Ethernet connectivity and provides high-performance uplinks
- With 2 USB ports, connect/disconnect devices while not having to shut down the system
- Serial Attached SCSI (SAS) interface provides quick data transfer and greater throughput
| General Information | |
|---|---|
| Manufacturer | ASUS Computer International |
| Manufacturer Part Number | RS500A-E12-RS4U-8TW |
| Manufacturer Website Address | http://www.asus.com |
| Brand Name | Asus |
| Product Model | RS500A-E12-RS4U-8TW |
| Product Name | RS500A-E12-RS4U-8TW Barebone System |
| Product Type | Barebone System | Processor |
| Number of Processors Supported | 1 |
| Processor Socket | Socket SP5 LGA-6096 |
| Processor Supported | EPYC |
| Processor Manufacturer | AMD | Chipset |
| Chipset Manufacturer | AMD | Memory |
| Maximum Memory Supported | 6 TB |
| Memory Technology | DDR4 SDRAM |
| Memory Standard | DDR5-4800/PC5-38400 |
| Number of Total Memory Slots | 24 | Controllers |
| Controller Type |
|
Display & Graphics |
| Graphics Controller Manufacturer | ASPEED |
| Graphics Controller Model | AST2600 | Network & Communication |
| Ethernet Technology | Gigabit Ethernet | I/O Expansions |
| Number of Total Expansion Bays | 4 |
| Number of 3.5" Bays | 4 |
| Total Number of Expansion Slots | 4.0 |
| Number of PCI Slots | 1 |
| Number of PCI Express x16 Slots | 3 | Interfaces/Ports |
| Total Number of USB Ports | 2 |
| Number of USB 3.2 Gen 1 Ports | 2 |
| Number of VGA Ports | 1 | Power Description |
| Number of Power Supplies Installed | 2 |
| Maximum Power Supply Wattage | 800 W | Physical Characteristics |
| Form Factor | Rack-mountable |
| Rack Height | 1U |
| Height | 1.73" (43.85 mm) |
| Width | 17.68" (449 mm) |
| Depth | 33.17" (842.50 mm) |
| Weight (Approximate) | 13.15 kg | Miscellaneous |
| Environmentally Friendly | Yes |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| UPC | 197105075719 |
